TECHNICAL INFORMATION
Flanges Dimensions
Flanges Dimensions
DIN 2642, DIN Connections
LOOSE FLANGE FOR FLANGE COLLAR PN 10
LOOSE FLANGE FOR FLANGE COLLAR PN 10
Nom Pipe size |
Flange D mm |
d5 mm |
b mm |
r mm |
k mm |
Drilling |
d2 mm |
Weight kg |
Collar g mm |
10 15 20 |
90 95 105 |
16 23 28 |
16 16 |
5 5 |
60 65 75 |
4 4 4 |
15 15 |
0.23 0.26 0.30 |
45 50 60 |
32 40 |
115 140 150 |
33 42 50 |
16 16 16 |
5 5 |
85 100 110 |
4 4 |
15 18 18 |
0.37 0.54 0.5 |
70 82 0.92 |
50 65 80 |
165 185 200 |
62 81 94 |
18 18 20 |
5 5 |
125 145 160 |
4 4 |
18 18 18 |
0.80 0.90 1.28 |
107 127 142 |
100 125 150 |
220 250 285 |
113 138 164 |
20 22 22 |
6 6 |
180 210 240 |
8 8 8 |
18 18 22 |
1.37 1.78 2.27 |
162 192 218 |
175 200 250 |
315 340 395 |
195 222 273 |
24 24 26 |
7 7 |
270 295 350 |
8 8 12 |
22 22 22 |
2.90 3.16 4.22 |
248 273 328 |
300 350 400 |
445 505 565 |
324 374 426 |
26 26 32 |
8 8 |
400 460 515 |
12 16 16 |
22 22 25 |
4.80 5.85 8.45 |
378 438 490 |
450 500 600 |
615 670 780 |
475 530 630 |
32 34 36 |
8 |
565 620 725 |
20 20 20 |
25 25 30 |
9.45 11.35 15.30 |
540 595 695 |
700 800 |
895 1015 |
730 832 |
40 44 |
10 10 |
840 950 |
24 24 |
30 34 |
21.40 30.50 |
810 916 |
